51.2v 65Ah golff cart lifepo4 lithiwm ïon batri pecyn cylch dwfn IP67

2024-06-28 03:25

Manyleb

Model	AIN51105W	AIN51105S	AIN5165S	AIN51150S	AIN76105S
Foltedd Enwol	51.2V	51.2V	51.2V	51.2V	76.8V
Cynhwysedd Enwol	105Ah	105Ah	65Ah	150Ah	105Ah
Rated Energy	5370Wh	5370Wh	3320Wh	7680Wh	5370Wh
Maximum Charge Voltage	58.4V	58.4V	58.4V	58.4V	87.6V
Uchafswm y Tâl Cyfredol	100A	100A	60A	150A	100A
Uchafswm Rhyddhau Parhaus Cyfredol	150A	150A	130A	200A	200A
Maximum Peak Discharge Current (30 seconds)	300A	300A	250A	300A	300A
Foltedd Torri Rhyddhau	43.2V	43.2V	43.2V	43.2V	43.2V
Driving Mileage	65-80km	65-80km	40-60km	90-120km	100-130km
Tymheredd Tâl	0 ~ + 55 ℃	0 ~ + 55 ℃	0 ~ + 55 ℃	0 ~ + 55 ℃	0 ~ + 55 ℃
Tymheredd Rhyddhau	-20 ~ + 60 ℃	-20 ~ + 60 ℃	-20 ~ + 60 ℃	-20 ~ + 60 ℃	-20 ~ + 60 ℃
Cycle Life (25℃, 0.5C, 100% DOD)	> 6000	> 6000	> 6000	> 6000	> 6000
Terminals	M8 Nut	M8 Nut	M8 Nut	M8 Nut	M8 Nut
Lefel Amddiffyn	IP67	IP65	IP65	IP65	IP65
Dimensions(mm)	547*334*245	457*298*253	465*243*228	675*325*260	674*338*275
Pwysau	48.3kg	49kg	32kg	71kg	72.8kg
Communication Protocol	CAN / RS485	RS485	RS485	CAN / RS485	CAN / RS485



Nodweddion Allweddol

1, PET is able to bear 850kg, avoid bulging

2, CCS vehicle-grade craft,integrated wires

3, Support RS485/CAN/Bluetooth etc

4, 3-4mm metal plates at both side

5, Reserve 1mm width for potential bulging

6, Distributed sampling system to solve sampling impedance problem.

Rydym yn Addo
Bydd pob cynnyrch profi 100% cyn ei anfon i sicrhau nad oes gan y cynnyrch unrhyw broblemau ansawdd.
2.We guarantee that within 12 months from the date of receipt of the goods, we will not include man-made damage. If there is any quality problem, we will provide return service.



Cais

Ein Ffatri

Pacio A Llongau

Cwestiynau Cyffredin

Q1:Can I have samples to test? And what is the lead time for sample orders?
A1:Yes, we can supply samples, the lead time for samples is 7-10 days. and buyer pays for sample cost and shipping cost.

C2: Ydych chi'n darparu gwasanaeth ôl-werthu?
A2: Yes, the warranty is 3 years, if any quality problems on our side in this period, we can send a new one as a replacement.

C3 Beth yw mantais eich cwmni?
A3: We only supply high-level quality of battery and we guarantee on-time shipment, we also provide excellent after-sales service

C4: Ydych chi'n derbyn OEM / ODM?
A4: Yes, it is available.

Q5: What is your lead time for mass production?
A5: Siarad cyffredinol, tua 25-30 diwrnod yn dibynnu ar wahanol eitemau ar ôl cael taliad i lawr a chadarnhad am y samplau.

Q6:Are your battery real capacity?
A6: Pob un o'n celloedd batri sydd â gallu Gradd A, 100% newydd a real.

C7: Ydych chi'n ffatri neu'n gwmni masnachu?
A7:ALL IN ONE Battery Technology Co Ltd is a professional rechargeable lithium-ion battery and LifePO4 battery manufacturer, welcome to visit.

C8: Pa fath o dystysgrifau sydd gennych chi?
A8: Gallwn ddarparu CE, ROHS, FCC, IEC62133, MSDS, UN38.3 os yw maint eich archeb yn fawr.
